Cincon Electronics Co., Ltd. is a global supplier of switch mode power conversion products to the communications, computer, industrial, medical and consumer markets. We design and manufacture industry standard, RoHS compliant, DC-DC converters, AC adapters and open frame AC-DC power supplies.
Our current offerings comprise over 1200 standard products including single & multiple output DC-DC converters from 1W to 200W , single & multiple output AC adapters from 5W to 100 W and AC-DC power modules from 5W to 1600W.
Cincon also offers modified standard and custom power conversion products. We're expert in the design and manufacture of power supplies engineered to customer requirements. Emphasis is placed on reliability, rapid prototyping and adherence to cost targets.
Products are designed-for-manufacturability using the latest simulation techniques, test equipment and computer aided design tools. Our wholly owned, ISO 9001 & 14001 factories in Taiwan and China are outfitted with state-of-the art manufacturing equipment, including SMT pick-and-place assembly machinery.
AC/DC Power Supplies :: Chassis | Din Rail Mount
TRG100A | PDF | 100 | 90-264VAC | Single 12V, 15V, 24V, 48V | 5.906 x 2.756 x 1.378 inches
150.00 x 70.00 x 35.00mm | AC-DC Switching Adapter |
| | | | | | |
AC/DC Power Supplies :: Open Frame | Enclosed | U-Chassis
CFM05 | PDF | 5 | 85-264VAC | Single 3.3V, 5V, 9V, 12V, 15V, 18V, 24V | 2.165 x 1.378 x 0.827 inches
55 x 35 x 21mm | AC-DC Converter Open Frame |
| | | | | | |
CFM10/15 | PDF | 10 | 85-264VAC | Single 3.3V, 5V, 9V, 12V, 15V, 24V | CFM10: 2.559 x 1.772 x 0.906 inches, 65 x 45 x 23mm
CFM15: 2.752 x 1.89 x 0.906, 69.90 x 48 x 23mm | AC-DC Converter Open Frame |
| | | | | | |
CFM10 | PDF | 10 | Universal | 3.3, 5, 12, 15, 24 | 1.77" W x 2.56" L x .91" H
65 x 45 x 23 mm | Open Frame, PCB Mountable |
| | | | | | |
CFM15 | PDF | 10 | Universal | 3.3, 5, 12, 15, 24 | 1.77" W x 2.56" L x .91" H
65 x 45 x 23 mm | Open Frame, PCB Mountable |
| | | | | | |
CFM20 | PDF | 20 | 85-264VAC | Single 3.3V, 5V, 9V, 12V, 15V, 24V | 3.501 x 2.000 x 0.906 inches
88.92 x 50.80 x 23.00mm | AC-DC Converter Open Frame |
| | | | | | |
CFM40/60 | PDF | 40 | 90-264VAC | Single 3.3V, 5V, 9V, 12V, 15V, 24V, 30V, 36V, 48V | 4.00 x 2.00 x 1.20 inches
101.60 x 50.80 x 30.48 | AC-DC Converter Open Frame |
| | | | | | |
CFM40D/T | PDF | 40 | 90-264VAC | Dual, Triple | 4.00 x 2.00 x 1.063 inches
101.60 x 50.80 x 27.00mm | AC-DC Converter Open Frame |
| | | | | | |
CFM60T | PDF | 60 | 90-264VAC | Triple | 4.00 x 2.00 x 1.26 inches
101.60 x 50.80 x 32.00 | AC-DC Converter Open Frame |
| | | | | | |
CFM100 | PDF | 100 | 90-264VAC | Single 5V, 9V, 12V, 15V, 18V, 24V, 48V | 5.00 x 3.00 x 1.339 inches
127.00 x 76.20 x 34.00mm | AC-DC Converter Open Frame |
| | | | | | |
CFM101S | PDF | 100 | 90-264VAC | Single 12V, 15V, 24V, 48V | 2.0 x 4.0 x 1.1 inches
101.6 x 50.6 x 27.94mm | AC-DC Converter Open Frame |
| | | | | | |
CFM200S | PDF | 200 | 90-264VAC | Single 3.3V, 5V, 9V, 12V, 15V, 18V, 24V, 28V, 30V, 36V, 48V | 5.91 x 3.94 x 1.5 inches
150 x 100 x 38.1mm | AC-DC Converter U Frame |
| | | | | | |
CFM350S | PDF | 350 | 90-264VAC | Single 12V, 15V, 24V, 36V, 48V | 9.26 x 4.00 x 1.59 inches
235.2 x 101.6 x 40.40mm | AC-DC Converter U Frame |
| | | | | | |
CFM750E | PDF | 750 | 90-264VAC | Single 24V, 36V, 48V | 11.02 x 4.00 x 1.65 inches
280.0 x 101.6 x 41.9mm | AC-DC Converter Enclosed |
| | | | | | |
CFM1600H | PDF | 1600 | 90-264VAC | Single 48V | 11.52 x 5.54 x 1.65 inches
292.6 x 140.7 x 42.0mm | AC-DC Converter Enclosed |
| | | | | | |
DC/DC :: PCB Mount
EC1SA | PDF | 1 | 5V--5~15VDC
12V--5~15VDC | Single, Dual 5V, 12V, 15V, ±5V, ±12V, ±15V | SIP: 0.77 x 0.24 x 0.40inches (19.5 x 6.1 x 10.2mm)
SMD Single: 0.5 x 0.31 x 0.27 inches (12.7 x 8.0 x 6.8mm)
SMD Dual: 0.6 x 0.31 x 0.27inches (15.24 x 8.0 x 6.8mm) | DC-DC Converter PCB Mount |
| | | | | | |
LAN-1 | PDF | 1 | 5VDC or 12VDC | 9V | 0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm | Pi Input Filter, 24 Pin DIP, Reg & Unreg |
| | | | | | |
EC2AN | PDF | 1 | 5VDC, 12VDC | Single, Dual 5, 12, 15, ±12, ±15 | 0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm | DC-DC Converter PCB Mount |
| | | | | | |
EC2SA | PDF | 2 | 4.5-9.0VDC, 9-18VDC, 18-36VDC, 36-75VDC | Single, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V | 0.86 x 0.36 x 0.44inches
21.80 x 9.20 x 11.10mm | DC-DC Converter PCB Mount |
| | | | | | |
EC2A | PDF | 2 | 5VDC, 12VDC, 24VDC, 28VDC, 48VDC | Single, Dual 5V, 12V, 15V, ±12V, ±15V | 0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm | DC-DC Converter PCB Mount |
| | | | | | |
EC3A | PDF | 3 | 4.5-6VDC, 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual 3.3V, 5V, 12V, 15V, ±12V, ±15V | 0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm | Pi Input Filter, 24 Pin DIP / SMD Avail. |
| | | | | | |
EC3SA | PDF | 3 | 4.5-9.0VDC, 9-18VDC, 18-36VDC, 36-75VDC | Single, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V | 0.86 x 0.36 x 0.44inches
21.80 x 9.20 x 11.10mm | DC-DC Converter PCB Mount |
| | | | | | |
EC3AE | PDF | 3 | 5VDC, 12VDC, 24VDC, 28VDC, 48VDC | Single, Dual 5V, 12V, 15V, ±12V, ±15V | 0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm | LC Input Filter, 24 Pin DIP Package, Regulated |
| | | | | | |
EC3AB | PDF | 3 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual 3.3V, 5V, 12V, 15V, ±12V, ±15V | 0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm | Pi Input Filter / Class B, 24 Pin DIP / SMD Avail |
| | | | | | |
SIPSMT05-05 | PDF | 5 | 3.0-5.5VDC, 4.5-5.5VDC | Single 0.75V, 1.2V, 1.5V, 1.8V, 2V, 2.5V, 3.3V | 0.90 x 0.400 x 0.22 inches
22.9 x 10.16 x 5.6mm | POL Converter PCB Mount |
| | | | | | |
EC2C | PDF | 5 | 5VDC, 12VDC, 24VDC, 28VDC, 48VDC | Single, Dual 5V, 12V, 15V, ±12V, ±15V | 2.00 x 2.00 x 0.40 inches
50.8 x 50.8 x 10.2mm | DC-DC Converter PCB Mount |
| | | | | | |
SIPSMT05-12 | PDF | 5 | 8.3-14VDC | Single 0.75V, 1.2V, 1.5V, 1.8V, 2V, 2.5V, 3.3V, 5V | 0.90 x 0.400 x 0.22 inches
22.9 x 10.16 x 5.6mm | POL Converter PCB Mount |
| | | | | | |
EC4A | PDF | 5 | 9-18VDC, 18-36VDC, 36-72VDC | 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V | 0.8 x 1.25 x 0.5 inches
20.3 x 31.8 x 12.7 mm | Pi Input Filter, 24 Pin DIP/ SMD Avail., 2:1 Input / Remote Inhib., Hi Isolation Optional |
| | | | | | |
EC4AB | PDF | 5 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V | 0.8 x 1.25 x 0.5 inches
20.3 x 31.8 x 12.7 mm | Pi Input Filter / Class B, 24 Pin DIP / SMD Avail., 2:1 Input / Remote Inhib., Hi Isolation Optiona |
| | | | | | |
EC4C | PDF | 5 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual 5V, 12V, 15V, ±12V, ±15V | 2.00 x 2.00 x 0.40 inches
50.8 x 50.8 x 10.2 mm | Pi Input Filter, Two Industry Standard Pin out Options, 2:1 Input |
| | | | | | |
EC4CE | PDF | 5 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual 5V, 12V, 15V, ±12V, ±15V | 2.00 x 2.00 x 0.40 inches
50.8 x 50.8 x 10.2 mm | Pi Input Filter, 2:1 Input |
| | | | | | |
EC4AW | PDF | 5 | 9-36VDC, 18-72VDC | Single, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V | 0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm | Pi Input Filter, 24 Pin DIP / SMD Avail., 4:1 Input, Hi Isolation Optional |
| | | | | | |
EC5A | PDF | 6 | 4.7-6VDC, 9-32VDC, 16-32VDC, 19-32VDC | Single 3.3V, 5V, 12V, 15V | 0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm | nput LC Filter, 24 Pin DIP / SMD Avail., Regulated / Non Isolated |
| | | | | | |
EC4AU | PDF | 6 | 9-18VDC, 18-36VDC, 36-75VDC | Single, Dual 3.3V, 5V, 12V, ±5V, ±12V, ±15V | 1.25 x 0.80 x 0.40 inches
31.8 x 20.3 x 10.2mm | DC-DC Converter PCB Mount |
| | | | | | |
EC6B | PDF | 7 | 4.5-5.5VDC | Single 1.2V, 2.1V, 2.5V, 3.3V | 1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm | Non Isolated, Regulated, Remote Inhibit |
| | | | | | |
EC6A | PDF | 8 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V | 0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm | Pi Input Filter, 24 Pin DIP / SMD Avail., 2:1 Input |
| | | | | | |
EC3B | PDF | 8 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V | 2.00 x 1.00 x 0.40 inches
50.8 x 25.4 x 10.2mm | i Input Filter, Industry Standard Pin Out, 2:1 Input |
| | | | | | |
EC3BB | PDF | 8 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V | 1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm | Pi Input Filter, EN55022 Class B, Remote Inhib. / 2:1 Inpu |
| | | | | | |
EC3AW | PDF | 9 | 9-36VDC, 18-72VDC | Single, Dual 3.3V, 5V, 12V, 15V, ±12V, ±15V | 0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm | Pi Input Filter, 24 Pin DIP / SMD Avail., 4:1 Input, Hi Isolation Optional |
| | | | | | |
EC4BW | PDF | 10 | 24V (9-36VDC) | 1,2 | 2x1x.4" - 50.8x25.4x10.2mm | regulated outputs, pi input filter |
| | | | | | |
SIPSMT10-05 | PDF | 10 | 3.0-5.5VDC, 4.5-5.5VDC | Single 1.0V, 1.2V, 1.5V, 1.8V, 2.0V, 2.5V, 3.3V | 2.00 x 0.50 x 0.33 inches
50.8 x 12.7 x 8.3mm | POL Converter PCB Mount |
| | | | | | |
EC4B | PDF | 10 | 4.7-9VDC, 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual 5V, 12V, 15V, ±5V, ±12V, ±15V | 1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm | Pi Input Filter, EN55022 Class B, 2:1 Input |
| | | | | | |
SIPSMT10W-12 | PDF | 10 | 6-14VDC | Single 0.7525V, 1.2V, 1.5V, 1.8V, 2.0V, 2.5V, 3.3V, 5.0V | 2.00 x 0.510 x 0.327 inches
50.8 x 12.95 x 8.30mm | POL Converter PCB Mount |
| | | | | | |
EC4BE | PDF | 10 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual 5V, 12V, 15V, ±5V, ±12V, ±15V | 1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm | Pi Input Filter, EN55022 Class B, 2:1 Input |
| | | | | | |
EC7A | PDF | 10 | 9-18VDC, 18-36VDC, 36-75VDC | Single, Dual 2.5V, 3.3V, 5V, 12V, 15V, ±12V, ±15v | 1.25 x 0.80 x 0.40 inches
31.8 x 20.3 x 10.2mm | DC-DC Converter PCB Mount |
| | | | | | |
SIPSMT10-12 | PDF | 10 | 9.0-14VDC | Single 0.75V, 1.2V, 1.5V, 1.8V, 2V, 2.5V, 3.3V, 5V | 2.00 x 0.512 x 0.327 inches
50.8 x 13.0 x 8.30mm | POL Converter PCB Mount |
| | | | | | |
EC8B | PDF | 11 | 18-36VDC, 36-75VDC | Single 1.8V, 2.5V, 3.3V, 5V | 1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm | Industry Standard Pin out, Open Frame |
| | | | | | |
EC1SB | PDF | 13 | 18-36VDC, 36-75VDC | Single 3.3V, 5V, 12V, 15V | 1.10 x 0.96 x 0.36 inches
27.9 x 24.4 x 9.1mm | Open Frame DC-DC Converter PCB Mount |
| | | | | | |
EC2SC | PDF | 14 | 9-18VDC, 18-36VDC, 36-75VDC | Single 1.8V, 2.5V, 3.3V, 5.0V, 12V, 15V | Metal Case: 1.60 x 2 .00 x 0.45 inches, 40.64 x 50.80 x 10.20 mm
Open Frame: 1.95 x 1.55 x 0.40 inches, 49.5 x 39.4 x 10.2mm | Open Frame, Industry Standard Pin out, 2:1 |
| | | | | | |
SIPSMT15-05 | PDF | 15 | 3-5.5VDC | Single 1.0V, 1.2V, 1.5V, 1.8V, 2.0V, 2.5V, 3.3V | 2.00 x 0.50 x 0.327 inches
50.8 x 12.7 x 8.50mm | POL Converter PCB Mount |
| | | | | | |
EC5B | PDF | 15 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V | 1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm | Pi Input Filter, EN55022 Class B, 2:1 Input |
| | | | | | |
EC5BE | PDF | 15 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V | 1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm | Pi Input / Trim Avail., EN55022 Class B, Remote Inhib / 2:1 Input |
| | | | | | |
EC3C | PDF | 15 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V | 2.00 x 2.00 x 0.40 inches
50.8 x 50.8 x 10.2 mm | Pi Input Filter, Two Industry Pin out, 2:1 Input |
| | | | | | |
EC3CB | PDF | 15 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V | 2.00 x 2.00 x 0.40 inches
50.8 x 50.8 x 10.2 mm | DC-DC Converter PCB Mount |
| | | | | | |
EC2EE | PDF | 15 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual, Triple 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V, 5/±12V, 5/±15V, +5/+12/-5V | 3 .00 x 2.56 x 0.83 inches
76.2 x 65 x 21.2 mm | ndustry Standard Pin out, 1-3 Outputs / Remote Inhibit, 2:1 Input / Trim |
| | | | | | |
EC4EE | PDF | 15 | 9-18VDC, 18-72VDC | Single, Dual, Triple 5V, 12V, 15V, ±12V, ±15V, 5/±12V, 5/±15V, +5/+12/-5V | 2.56 x 3.00 x 0.83 inches
65 x 76.2 x 21.1 mm | Industry Standard Pin out, 4:1 Input |
| | | | | | |
EC5C | PDF | 15 | 9-36VDC, 18-72VDC | Single, Dual, Triple 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V, 5/±12V, 5/±15V | 2.00 x 2.00 x 0.40 inches
50.8 x 50.8 x 10.2 mm | Industry Standard Pin out, 1-3 Outputs, Remote Inhibit / Trim, 4:1 Input |
| | | | | | |
SIPSMT16W-12 | PDF | 16 | 6-14VDC | Single 0.7525V, 1.2V, 1.5V, 1.8V, 2.0V, 2.5V, 3.3V, 5.0V | 2.00 x 0.510 x 0.327 inches
50.8 x 12.95 x 8.30mm | POL Converter PCB Mount |
| | | | | | |
SIPSMT16-12 | PDF | 16 | 9-14VDC | Single 0.75V, 1.2V, 1.5V, 1.8V, 2V, 2.5V, 3.3V, 5V | 2.00 x 0.512 x 0.327 inches
50.8 x 13.0 x 8.30mm | POL Converter PCB Mount |
| | | | | | |
SIPSMT20W-12 | PDF | 20 | 6-14VDC | Single 0.7525V, 1.2V, 1.5V, 1.8V, 2.0V, 2.5V, 3.3V, 5.0V | 2.40 x 0.510 x 0.327 inches
61.0 x 12.95 x 8.3mm | POL Converter PCB Mount |
| | | | | | |
EC7B | PDF | 20 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual 1.8V, 2.5V, 3.3V, 5V, 12V, 15V, ±12V, ±15V | 1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm | Remote Inhibit / Trim, 2:1 Input |
| | | | | | |
EC1SC | PDF | 20 | 9-36VDC, 18-72VDC | Single, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V | 2.00 x 1.60 x 0.45 inches
50.8 x 40.6 x 11.4mm | Pi Filter, Remote Inhib., UL Recognized, 4:1 Input Range |
| | | | | | |
EC7BW | PDF | 20 | 9-36VDC, 18-75VDC | Single 3.3V, 5V, 12V, 15V | 1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm | DC-DC Converter PCB Mount |
| | | | | | |
EC3SCW | PDF | 20 | 9-36VDC, 18-75VDC | Single 3V, 5V, 12V, 15V | 2.00 x 1.60 x 0.40 inches
50.8 x 40.6 x 10.2mm | DC-DC Converter PCB Mount |
| | | | | | |
EC6C | PDF | 25 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual, Triple 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V, 5/±12V, 5/±15V | 2.00 x 2.00 x 0.40 inches
50.8 x 50.8 x 10.2 mm | Industry Standard Pin out, 1-3 Outputs / Remote Inhibit, 2:1 Input / Trim |
| | | | | | |
EC5E | PDF | 25 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual, Triple 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V, 5/±12V, 5/±15V, +5/+12/-5V | 2.56 x 3.00 x 0.83 inches
65 x 76.2 x 21.1 mm | industry Standard Pin out, 2:1 Input / Trim |
| | | | | | |
EC6E | PDF | 25 | 9-18VDC, 18-36VDC, 36-72VDC | Single, Dual, Triple 5V, 12V, 15V, ±12V, ±15V, 5/±12V, 5/±15V, +5/+12/-5V | 2.56 x 3.00 x 0.83 inches
65 x 76.2 x 21.1 mm | Industry Standard Pin out, 4:1 Input / Trim |
| | | | | | |
CHB50 | PDF | 25 | 9-18VDC, 18-36VDC, 36-75VDC | Single 2.5V, 3.3V, 5V, 12V, 15V, 24V | 2.28 x 2.40 x 0.50 inches
57.9 x 61.0 x 12.7 mm | DC-DC Converter PCB Mount |
| | | | | | |
CHB50W | PDF | 25 | 9-36VDC, 18-75VDC | Single 3.3V, 5V, 12V, 15V, 24V | 2.28 x 2.40 x 0.50 inches
57.9 x 61.0 x 12.7 | DC-DC Converter PCB Mount |
| | | | | | |
CEB75 | PDF | 30 | 36-75VDC | Single 1V,1.2V, 1.5V, 1.8V, 2.5V, 3.3V, 5V, 12V | 2.30 x 0.90 x 0.39 inches
58.4 x 22.9 x 10.0mm | DC-DC Converter PCB Mount |
| | | | | | |
CHB75 | PDF | 38 | 9-18VDC, 18-36VDC, 36-75VDC | Single 2.5V, 3.3V, 5V, 12V, 15V, 24V | 2.28 x 2.40 x 0.50 inches
57.9 x 61.0 x 12.7mm | DC-DC Converter PCB Mount |
| | | | | | |
CHB75W | PDF | 38 | 9-36VDC, 18-75VDC | Single 3.3V, 5V, 12V, 15V, 24V | 2.28 x 2.40 x 0.50 inches
57.9 x 61.0 x 12.7 | Half Brick, 4:1 Input, Single Output |
| | | | | | |
CQB125 | PDF | 40 | 36-75VDC | Single 1V, 1.2V, 1.5V, 1.8V, 2.5V, 3.3V, 5V, 12V | 2.30 x 1.45 x 0.42 inches
58.4 x 36.8 x 10.6mm | DC-DC Converter PCB Mount |
| | | | | | |
EC7C | PDF | 40 | 9-18VDC, 18-36VDC, 36-75VDC | Single, Dual, Triple 2.5V, 3.3V, 5V, 12V, 15V, ±12V, ±15V, 3.3V/5.0V, 3.3/±12V, 3.3/±15V, 5.0/±12V, 5.0/±15V | 2.00 x 2.00 x 0.40 inches
50.8 x 50.8 x 10.2 mm | DC-DC Converter PCB Mount |
| | | | | | |
PKQ75 | PDF | 50 | 18-36VDC, 36-75VDC | Single 1.8V, 2.5V, 3.3V, 5V | 1.45 x 2.28 x 0.50 inches
36.8 x 57.9 x 12.7 mm | DC-DC Converter PCB Mount |
| | | | | | |
CHB100 | PDF | 50 | 18-36VDC, 36-75VDC | Single 2.5V, 3.3V, 5V, 12V, 15V, 24V | 2.28 x 2.40 x 0.50 inches
57.9 x 61.0 x 12.7mm | DC-DC Converter PCB Mount |
| | | | | | |
CHB100W | PDF | 66 | 9-36VDC, 18-75VDC | Single 3.3V, 5V, 12V, 15V, 24V | 2.28 x 2.40 x 0.50 inches
57.9 x 61.0 x 12.7mm | DC-DC Converter PCB Mount |
| | | | | | |
CHB75-Dual | PDF | 75 | 18-36VDC, 36-75VDC | Dual 2.5V, 3.3V, 5V | 2.28 x 2.40 x 0.52 inches
57.9 x 61.0 x 13.2mm | DC-DC Converter PCB Mount |
| | | | | | |
CHB150 | PDF | 75 | 36-75VDC | Single 2.5V, 3.3V, 5V, 12V, 15V, 24V | 2.28 x 2.40 x 0.50 inches
57.9 x 61.0 x 12.7mm | DC-DC Converter PCB Mount |
| | | | | | |
CQB75W | PDF | 75 | 9-36VDC, 18-75VDC | Single 3.3V, 5V, 12V, 15V, 24V | 1.45 x 2.28 x 0.50 inches
36.8 x 57.9 x 12.7 mm | DC-DC Converter PCB Mount |
| | | | | | |
CHB150W | PDF | 99 | 9-36VDC, 18-75VDC | Single 3.3V, 5V, 12V, 15V, 24V | 2.28 x 2.40 x 0.52 inches
57.9 x 61.0 x 13.2mm | DC-DC Converter PCB Mount |
| | | | | | |
CQB100W | PDF | 100 | 18-75VDC | Single 3.3V, 5V, 12V, 15V, 24V | 1.45 x 2.26 x 0.50 inches
36.8 x 57.9 x 12.7 mm | DC-DC Converter PCB Mount |
| | | | | | |
CFB200 | PDF | 100 | 36-75VDC | Single 2.5V, 3.3V, 5V, 12V, 15V, 24V, 28V, 48V | 4.60 x 2.40 x 0.52 inches
116.8 x 61.0 x 13.2mm | DC-DC Converter PCB Mount |
| | | | | | |
CHB200W | PDF | 132 | 18-75VDC | Single 3.3V, 5V, 12V, 15V, 24V | 2.28 x 2.40 x 0.52 inches
57.9 x 61.0 x 13.2mm | DC-DC Converter PCB Mount |
| | | | | | |
IBQ | PDF | 180 | 42-53VDC, 36-75VDC | Single 12V | 2.28 x 1.45 x 0.40 inches
57.9 x 36.8 x 10.2mm | DC-DC Converter PCB Mount |
| | | | | | |
AC/DC Power Supplies :: Tabletop | Wallmount
TR500 | PDF | 6 | 90-264VAC | Single 4.2V, 5.0V, 6.0V, 6.5V, 7.0V, 7.5V, 7.5V, 8V, 9V, 10V, 12V | 2.835 x 2.047 x 1.378 inches
72.00 x 52.00 x 35.00mm | AC-DC Switching Adapter |
| | | | | | |
TRG500 | PDF | 6 | 90-264VAC | Single 5.0V, 6.0V, 6.5V, 7.0V, 7.5V, 7.5V, 8V, 9V, 10V, 12V | 2.835 x 2.047 x 1.378 inches
72.00 x 52.00 x 35.00mm | AC-DC Switching Adapter |
| | | | | | |
TR10R | PDF | 10 | 90-264VAC | Single 3.3V, 5V, 6V, 7.5V, 9V, 12V, 13.6V, 15V, 18V, 24V | 2.835 x 1.811 x 1.378 inches
72.00 x 46.00 x 35.00mm | AC-DC Switching Adapter |
| | | | | | |
TRG10R | PDF | 10 | 90-264VAC | Single 5V, 6V, 7.5V, 9V, 12V, 13.6V, 15V, 18V, 24V | 2.835 x 1.811 x 1.378 inches
72.00 x 46.00 x 35.00mm | AC-DC Switching Adapter |
| | | | | | |
TR15 | PDF | 15 | 90-264VAC | Single 5V, 6V, 7.5V, 9V, 12V, 13.6V, 15V, 18V, 24V | 2.835 x 2.047 x 1.378 inches
72.00 x 52.00 x 35.00mm | AC-DC Switching Adapter |
| | | | | | |
TRG15 | PDF | 15 | 90-264VAC | Single 5V, 6V, 7.5V, 9V, 12V, 13.6V, 15V, 18V, 24V | 2.835 x 2.047 x 1.378 inches
72.00 x 52.00 x 35.00mm | AC-DC Switching Adapter |
| | | | | | |
TR15RA | PDF | 15 | 90-264VAC | Single 5V, 6V, 9V, 12V, 15V, 18V, 24V | 3.173 x 1.885 x 1.705 inches
80.60 x 47.90 x 43.30 | AC-DC Switching Adapter |
| | | | | | |
TR20B | PDF | 20 | 90-264VAC | Single 3.3V, 5V, 9V, 12V, 15V, 18V, 24V | 4.331 x 1.969 x 1.181 inches
110.00 x 50.00 x 30.00mm | AC-DC Switching Adapter |
| | | | | | |
TR25 | PDF | 25 | 100-240VAC | Single 3.3V, 5V, 12V, 15V, 18V, 24V | 3.169 x 1.932 x 2.205 inches
80.50 x 49.06 x 56.00mm | AC-DC Switching Adapter |
| | | | | | |
TRG25 | PDF | 25 | 100-240VAC | Single 3.3V, 5V, 12V, 15V, 18V, 24V | 3.169 x 1.932 x 2.205 inches
80.50 x 49.06 x 56.00mm | AC-DC Switching Adapter |
| | | | | | |
TR25D | PDF | 25 | 90-264VAC | Dual | 5.197 x 2.283 x 1.181 inches
132.00 x 58.00 x 30.00mm | AC-DC Switching Adapter |
| | | | | | |
TR30R | PDF | 30 | 90-264VAC | Single 5V, 9V, 12V, 15V, 18V, 24V | 4.234 x 2.267 x 1.319 inches
107.77 x 57.60 x 33.50mm | AC-DC Switching Adapter |
| | | | | | |
TRG30R | PDF | 30 | 90-264VAC | Single 9V, 12V, 15V, 18V, 24V | 4.234 x 2.267 x 1.319 inches
107.77 x 57.60 x 33.50mm | AC-DC Switching Adapter |
| | | | | | |
TR30RA | PDF | 30 | 90-264VAC | Single 5V, 9V, 12V, 15V, 18V, 24V | 4.278 x 2.440 x 1.445 inches
108.67 x 61.89 x 36.70mm | AC-DC Switching Adapter |
| | | | | | |
TRG30RA | PDF | 30 | 90-264VAC | Single 9V, 12V, 15V, 18V, 24V | 4.278 x 2.440 x 1.445 inches
108.67 x 61.89 x 36.70mm | AC-DC Switching Adapter |
| | | | | | |
TR30RAM | PDF | 30 | 90-264VAC | Single 5V, 9V, 12V, 15V, 18V, 24V | 4.270 x 2.440 x 1.445 inches
108.67 x 61.98 x 36.70mm | AC-DC Medical Switching Adapter |
| | | | | | |
TR30M | PDF | 30 | 90-264VAC | Single 5V, 9V, 12V, 15V, 18V, 24V | 4.331 x 1.969 x 1.181 inches
110.00 x 50.00 x 30.00mm | AC-DC Switching Adapter |
| | | | | | |
TR36 | PDF | 36 | 90-264VAC | Single 5V, 9V, 12V, 13.5V, 15V, 18V, 24V, 48V | 4.331 x 1.969 x 0.787 inches
110.00 x 50.00 x 20.00mm | AC-DC Switching Adapter |
| | | | | | |
TRG36 | PDF | 36 | 90-264VAC | Single 5V, 9V, 12V, 13.5V, 15V, 18V, 24V, 48V | 4.331 x 1.969 x 0.787 inches
110.00 x 50.00 x 20.00mm | AC-DC Switching Adapter |
| | | | | | |
TR45 | PDF | 45 | 90-264VAC | Single 5V, 12V, 15V, 18V, 19, 24V, 48V | 5.197 x 2.283 x 1.181 inches
132.00 x 58.00 x 30.00mm | AC-DC Switching Adapter |
| | | | | | |
TRG45 | PDF | 45 | 90-264VAC | Single 12V, 15V, 18V, 19V, 24V, 48V | 4.724 x 2.047 x 1.220 inches
120.00 x 52.00 x 31.00mm | AC-DC Switching Adapter |
| | | | | | |
TR60M | PDF | 60 | 90-264VAC | Single 5V, 12V, 15V, 18V, 19, 24V | 5.197 x 2.283 x 1.201 inches
132.00 x 58.00 x 30.50mm | AC-DC Medical Switching Adapter |
| | | | | | |
TR60A-POE-L | PDF | 60 | 90-264VAC | Single 48V | 5.91 x 2.76 x 1.38 inches
150 x 70 x 35mm | AC-DC POE Adapter |
| | | | | | |
TR70 | PDF | 70 | 90-264VAC | Single 12V, 15V, 18V, 19V, 24V, 48V | 5.197 x 2.283 x 1.181 inches
132.00 x 58.00 x 30.00mm | AC-DC Switching Adapter |
| | | | | | |
TRG70 | PDF | 70 | 90-264VAC | Single 12V, 15V, 18V, 19V, 24V, 48V | 5.197 x 2.283 x 1.201 inches
132.00 x 58.00 x 30.50mm | AC-DC Switching Adapter |
| | | | | | |
TRG70E | PDF | 70 | 90-264VAC | Single 12V, 15V, 18V, 19V, 24V, 48V | 5.197 x 2.283 x 1.201 inches
132.00 x 58.00 x 30.50mm | AC-DC Switching Adapter |
| | | | | | |
TR100 | PDF | 100 | 90-264VAC | Single 12V, 15V, 18V, 19V, 24V, 28V, 29V, 30V, 36V, 48V | 5.906 x 2.756 x 1.378 inches
150.00 x 70.00 x 35.00mm | AC-DC Switching Adapter |
| | | | | | |
TRG150A | PDF | 150 | 90-264VAC | Single 12V, 15V, 24V, 48V | 7.08 x 2.91 x 1.61 inches
180.00 x 74.00 x 41.00mm | AC-DC Switching Adapter |
| | | | | | |
|
|
