DC/DC Power Supplies :: PCB Mount

Arch Electronics

Series  DataSheet    Power  Input RangeOutputsDimensionsFeatures

SB1R5		PDF25V--4.5~5.5VDC
12V--10.8~13.2VDC
24V--21.6~26.4VDC
48V--43.2~52.8VDC		Single/Dual 5, 12, 15, 24
±5, ±12, ±15		1.25 x 0.8 x 0.4 In
31.8 x 20.3 x 10.2 mm		DC-DC PCB Mount


SB03		PDF312V--9~36VDCbr>24V--18~75VDCSingle/Dual 3.3, 5, 12, 15, 24
±5, ±12, ±15		1.25 x 0.8 x 0.4 In
31.8 x 20.3 x 10.2 mm		DC-DC PCB Mount


SB05		PDF512V--9~36VDC
24V--18~75VDC		Single/Dual 3.3, 5, 12, 15, 24
±5, ±12, ±15		1.25 x 0.8 x 0.4 In
31.8 x 20.3 x 10.2 mm		DC-DC PCB Mount


SH05		PDF524V--9~36VDC
48V--18~75VDC		Single/Dual 3.3, 5, 12, 15, 24
±5, ±12, ±15		1.25 x 0.8 x 0.44 In
31.8 x 20.3 x 11.2 mm		DC-DC PCB Mount


ZA05		PDF524V--9~36VDC
48V--18~75VDC		Single/Dual 3.3, 5, 12, 15, 24
±5, ±12, ±15		1.25 x 0.8 x 0.4 In31.8 x 20.3 x 10.2 mmDC-DC PCB Mount


SH08		PDF824v--9~36VDC
48V--18~75VDC		Single/Dual 5, 12, 15, 24
±5, ±12, ±15		1.25 x 0.8 x 0.44 In
31.8 x 20.3 x 11.2 mm		DC-DC PCB Mount


SB08		PDF82:1 Range: 12V--9~18, 24V--18~36, 48V--36~75VDC
4:1 Range: 24V--9~36, 48V--18~75VDC		Single/Dual 3.3, 5, 12, 15, 24
±5, ±12, ±15		1.25 x 0.8 x 0.4 In
31.8 x 20.3 x 10.2 mm		DC-DC PCB Mount


ST10		PDF102:1 Range: 12V--9~18, 24V--18~36, 28V--36~75VDC
4:1 Range: 24V--10~40, 48V--36~75VDC		Single/Dual 3.3, 5, 12, 15, 24
±5, ±12, ±15		1.97 x 1.0 x 0.425 In
50.1 x 25.4 x 10.8 mm		DC-DC PCB Mount


SW15		PDF15128V--9~1VDC
24V--18~36VDC
48V--36~75		Single 3.3, 5, 12, 151.0 x 1.0 x 0.433 In
25.4 x 25.4 x 11.0 mm		DC-DC PCB Mount


ZB15		PDF1512V--9~18VDC
24V--18~36VDC
48V--36~75VDC		Single/Dual 3.3, 5, 12, 15, 24
±5, ±12, ±15		1.97 x 1.0 x 0.425 In
50.1 x 25.4 x 10.8 mm		DC-DC PCB Mount


ST15		PDF152:1 Range: 12V--9~18, 24V--18~36, 48V--36~75VDC
4:1 Range: 24V--10~40, 48V--18~75VDC		Single/Dual 3.3, 5, 12, 15, 24
±5, ±12, ±15		1.97 x 1.0 x 0.425 In
50.1 x 25.4 x 10.8 mm		DC-DC PCB Mount


SW20		PDF2012V--9~18VDC
24V--18~36VDC
48V--36~75VDC		Single 3.3, 5, 12, 151.0 x 1.0 x 0.433 In
25.4 x 25.4 x 11.0 mm		DC-DC PCB Mount


SU20		PDF202:1 Range: 12V--9~18, 24V--18~36, 48V--36~75VDC
4:1 Range: 24V--10~40, 48V--18~75VDC		Single/Dual/Triple 3.3, 5, 12, 15, 24
±5, ±12, ±15
5/±12, 5/±15		2.0 x 2.0 x 0.45 In
50.8 x 50.8 x 11.4 mm		DC-DC PCB Mount


ST20		PDF202:1 Range: 24V--18~36VDC
48V--36~75VDC		Single 2.5, 3.3, 51.97 x 1.0 x 0.425 In
50.1 x 25.4 x 10.8 mm		DC-DC PCB Mount


SF30		PDF3024V--10~40VDC
48V--18~75VDC		Single/Dual 2.5, 3.3, 5, 12, 15, 24
±5, ±12, ±15		2.0 x 1.6 x 0.47 In
50.8 x 40.6 x 11.9 mm		DC-DC PCB Mount


ST30 		PDF3024V--18~36VDC
48V--36~75VDC		Single/Dual 2.5, 3.3, 5, 12, 15, 24
±5, ±12, ±15		2.0 x 1.0 x 0.433 In
50.8 x 25.4 x 11.0 mm		DC-DC PCB Mount


SK30		PDF3048V--36~75VDCSingle 1.8, 2.5, 3.3, 5, 12, 15, 242.0 x 1.6 x 0.47 In
50.8 x 40.6 x 11.9 mm		DC-DC PCB Mount


SU40		PDF402:1 Range: 12V--9~18, 24V--18~36, 48V--36~75VDCSingle/Dual/Triple 1.8, 2.5, 3.3, 5, 12, 15, 24
±5, ±12, ±15
5/±12, 5/±15		2.0 x 2.0 x 0.45 In
50.8 x 50.8 x 11.4 mm		DC-DC PCB Mount


SK40		PDF4048V--36~75VDCSingle 1.8, 2.5, 3.3, 5, 12, 15, 242.0 x 1.60 x 0.47 In
50.80 x 40.6 x 11.90 mm		DC-DC PCB Mount

Cincon

Series  DataSheet    Power  Input RangeOutputsDimensionsFeatures

EC1SA		PDF15V--5~15VDC
12V--5~15VDC		Single, Dual 5V, 12V, 15V, ±5V, ±12V, ±15VSIP: 0.77 x 0.24 x 0.40inches (19.5 x 6.1 x 10.2mm)
SMD Single: 0.5 x 0.31 x 0.27 inches (12.7 x 8.0 x 6.8mm)
SMD Dual: 0.6 x 0.31 x 0.27inches (15.24 x 8.0 x 6.8mm)		DC-DC Converter PCB Mount


LAN-1		PDF15VDC or 12VDC9V0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm		Pi Input Filter, 24 Pin DIP, Reg & Unreg


EC2AN		PDF15VDC, 12VDCSingle, Dual 5, 12, 15, ±12, ±15 0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm		DC-DC Converter PCB Mount


EC2SA		PDF24.5-9.0VDC, 9-18VDC, 18-36VDC, 36-75VDCSingle, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V0.86 x 0.36 x 0.44inches
21.80 x 9.20 x 11.10mm		DC-DC Converter PCB Mount


EC2A		PDF25VDC, 12VDC, 24VDC, 28VDC, 48VDCSingle, Dual 5V, 12V, 15V, ±12V, ±15V0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm		DC-DC Converter PCB Mount


EC3A		PDF34.5-6VDC, 9-18VDC, 18-36VDC, 36-72VDCSingle, Dual 3.3V, 5V, 12V, 15V, ±12V, ±15V0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm		Pi Input Filter, 24 Pin DIP / SMD Avail.


EC3SA		PDF34.5-9.0VDC, 9-18VDC, 18-36VDC, 36-75VDCSingle, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V0.86 x 0.36 x 0.44inches
21.80 x 9.20 x 11.10mm		DC-DC Converter PCB Mount


EC3AE		PDF35VDC, 12VDC, 24VDC, 28VDC, 48VDCSingle, Dual 5V, 12V, 15V, ±12V, ±15V0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm		LC Input Filter, 24 Pin DIP Package, Regulated


EC3AB		PDF39-18VDC, 18-36VDC, 36-72VDCSingle, Dual 3.3V, 5V, 12V, 15V, ±12V, ±15V0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm		Pi Input Filter / Class B, 24 Pin DIP / SMD Avail


SIPSMT05-05		PDF53.0-5.5VDC, 4.5-5.5VDCSingle 0.75V, 1.2V, 1.5V, 1.8V, 2V, 2.5V, 3.3V0.90 x 0.400 x 0.22 inches
22.9 x 10.16 x 5.6mm		POL Converter PCB Mount


EC2C		PDF55VDC, 12VDC, 24VDC, 28VDC, 48VDCSingle, Dual 5V, 12V, 15V, ±12V, ±15V2.00 x 2.00 x 0.40 inches
50.8 x 50.8 x 10.2mm		DC-DC Converter PCB Mount


SIPSMT05-12		PDF58.3-14VDCSingle 0.75V, 1.2V, 1.5V, 1.8V, 2V, 2.5V, 3.3V, 5V0.90 x 0.400 x 0.22 inches
22.9 x 10.16 x 5.6mm		POL Converter PCB Mount


EC4A		PDF59-18VDC, 18-36VDC, 36-72VDC3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V0.8 x 1.25 x 0.5 inches
20.3 x 31.8 x 12.7 mm		Pi Input Filter, 24 Pin DIP/ SMD Avail., 2:1 Input / Remote Inhib., Hi Isolation Optional


EC4AB		PDF59-18VDC, 18-36VDC, 36-72VDCSingle, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V0.8 x 1.25 x 0.5 inches
20.3 x 31.8 x 12.7 mm		Pi Input Filter / Class B, 24 Pin DIP / SMD Avail., 2:1 Input / Remote Inhib., Hi Isolation Optiona


EC4C		PDF59-18VDC, 18-36VDC, 36-72VDCSingle, Dual 5V, 12V, 15V, ±12V, ±15V2.00 x 2.00 x 0.40 inches
50.8 x 50.8 x 10.2 mm		Pi Input Filter, Two Industry Standard Pin out Options, 2:1 Input


EC4CE		PDF59-18VDC, 18-36VDC, 36-72VDCSingle, Dual 5V, 12V, 15V, ±12V, ±15V2.00 x 2.00 x 0.40 inches
50.8 x 50.8 x 10.2 mm		Pi Input Filter, 2:1 Input


EC4AW		PDF59-36VDC, 18-72VDCSingle, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm		Pi Input Filter, 24 Pin DIP / SMD Avail., 4:1 Input, Hi Isolation Optional


EC5A		PDF64.7-6VDC, 9-32VDC, 16-32VDC, 19-32VDCSingle 3.3V, 5V, 12V, 15V0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm		nput LC Filter, 24 Pin DIP / SMD Avail., Regulated / Non Isolated


EC4AU		PDF69-18VDC, 18-36VDC, 36-75VDCSingle, Dual 3.3V, 5V, 12V, ±5V, ±12V, ±15V1.25 x 0.80 x 0.40 inches
31.8 x 20.3 x 10.2mm		DC-DC Converter PCB Mount


EC6B		PDF74.5-5.5VDCSingle 1.2V, 2.1V, 2.5V, 3.3V1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm		Non Isolated, Regulated, Remote Inhibit


EC6A		PDF89-18VDC, 18-36VDC, 36-72VDCSingle, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm		Pi Input Filter, 24 Pin DIP / SMD Avail., 2:1 Input


EC3B		PDF89-18VDC, 18-36VDC, 36-72VDCSingle, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V2.00 x 1.00 x 0.40 inches
50.8 x 25.4 x 10.2mm		i Input Filter, Industry Standard Pin Out, 2:1 Input


EC3BB		PDF89-18VDC, 18-36VDC, 36-72VDCSingle, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm		Pi Input Filter, EN55022 Class B, Remote Inhib. / 2:1 Inpu


EC3AW		PDF99-36VDC, 18-72VDCSingle, Dual 3.3V, 5V, 12V, 15V, ±12V, ±15V0.8 x 1.25 x 0.4 inches
20.3 x 31.8 x 10.2 mm		Pi Input Filter, 24 Pin DIP / SMD Avail., 4:1 Input, Hi Isolation Optional


EC4BW		PDF1024V (9-36VDC)1,22x1x.4" - 50.8x25.4x10.2mmregulated outputs, pi input filter


SIPSMT10-05		PDF103.0-5.5VDC, 4.5-5.5VDCSingle 1.0V, 1.2V, 1.5V, 1.8V, 2.0V, 2.5V, 3.3V2.00 x 0.50 x 0.33 inches
50.8 x 12.7 x 8.3mm		POL Converter PCB Mount


EC4B		PDF104.7-9VDC, 9-18VDC, 18-36VDC, 36-72VDCSingle, Dual 5V, 12V, 15V, ±5V, ±12V, ±15V1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm		Pi Input Filter, EN55022 Class B, 2:1 Input


SIPSMT10W-12 		PDF106-14VDCSingle 0.7525V, 1.2V, 1.5V, 1.8V, 2.0V, 2.5V, 3.3V, 5.0V 2.00 x 0.510 x 0.327 inches
50.8 x 12.95 x 8.30mm		POL Converter PCB Mount


EC4BE		PDF109-18VDC, 18-36VDC, 36-72VDCSingle, Dual 5V, 12V, 15V, ±5V, ±12V, ±15V1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm		Pi Input Filter, EN55022 Class B, 2:1 Input


EC7A		PDF109-18VDC, 18-36VDC, 36-75VDCSingle, Dual 2.5V, 3.3V, 5V, 12V, 15V, ±12V, ±15v1.25 x 0.80 x 0.40 inches
31.8 x 20.3 x 10.2mm		DC-DC Converter PCB Mount


SIPSMT10-12		PDF109.0-14VDCSingle 0.75V, 1.2V, 1.5V, 1.8V, 2V, 2.5V, 3.3V, 5V2.00 x 0.512 x 0.327 inches
50.8 x 13.0 x 8.30mm		POL Converter PCB Mount


EC8B		PDF1118-36VDC, 36-75VDCSingle 1.8V, 2.5V, 3.3V, 5V1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm		Industry Standard Pin out, Open Frame


EC1SB		PDF1318-36VDC, 36-75VDCSingle 3.3V, 5V, 12V, 15V1.10 x 0.96 x 0.36 inches
27.9 x 24.4 x 9.1mm		Open Frame DC-DC Converter PCB Mount


EC2SC		PDF149-18VDC, 18-36VDC, 36-75VDCSingle 1.8V, 2.5V, 3.3V, 5.0V, 12V, 15VMetal Case: 1.60 x 2 .00 x 0.45 inches, 40.64 x 50.80 x 10.20 mm
Open Frame: 1.95 x 1.55 x 0.40 inches, 49.5 x 39.4 x 10.2mm		Open Frame, Industry Standard Pin out, 2:1


SIPSMT15-05		PDF153-5.5VDCSingle 1.0V, 1.2V, 1.5V, 1.8V, 2.0V, 2.5V, 3.3V2.00 x 0.50 x 0.327 inches
50.8 x 12.7 x 8.50mm		POL Converter PCB Mount


EC5B		PDF159-18VDC, 18-36VDC, 36-72VDCSingle, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm		Pi Input Filter, EN55022 Class B, 2:1 Input


EC5BE		PDF159-18VDC, 18-36VDC, 36-72VDCSingle, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm		Pi Input / Trim Avail., EN55022 Class B, Remote Inhib / 2:1 Input


EC3C		PDF159-18VDC, 18-36VDC, 36-72VDCSingle, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V2.00 x 2.00 x 0.40 inches
50.8 x 50.8 x 10.2 mm		Pi Input Filter, Two Industry Pin out, 2:1 Input


EC3CB		PDF159-18VDC, 18-36VDC, 36-72VDCSingle, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V2.00 x 2.00 x 0.40 inches
50.8 x 50.8 x 10.2 mm		DC-DC Converter PCB Mount


EC2EE		PDF159-18VDC, 18-36VDC, 36-72VDCSingle, Dual, Triple 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V, 5/±12V, 5/±15V, +5/+12/-5V3 .00 x 2.56 x 0.83 inches
76.2 x 65 x 21.2 mm		ndustry Standard Pin out, 1-3 Outputs / Remote Inhibit, 2:1 Input / Trim


EC4EE		PDF159-18VDC, 18-72VDCSingle, Dual, Triple 5V, 12V, 15V, ±12V, ±15V, 5/±12V, 5/±15V, +5/+12/-5V2.56 x 3.00 x 0.83 inches
65 x 76.2 x 21.1 mm		Industry Standard Pin out, 4:1 Input


EC5C		PDF159-36VDC, 18-72VDCSingle, Dual, Triple 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V, 5/±12V, 5/±15V2.00 x 2.00 x 0.40 inches
50.8 x 50.8 x 10.2 mm		Industry Standard Pin out, 1-3 Outputs, Remote Inhibit / Trim, 4:1 Input


SIPSMT16W-12		PDF166-14VDCSingle 0.7525V, 1.2V, 1.5V, 1.8V, 2.0V, 2.5V, 3.3V, 5.0V 2.00 x 0.510 x 0.327 inches
50.8 x 12.95 x 8.30mm		POL Converter PCB Mount


SIPSMT16-12		PDF169-14VDCSingle 0.75V, 1.2V, 1.5V, 1.8V, 2V, 2.5V, 3.3V, 5V2.00 x 0.512 x 0.327 inches
50.8 x 13.0 x 8.30mm		POL Converter PCB Mount


SIPSMT20W-12		PDF206-14VDCSingle 0.7525V, 1.2V, 1.5V, 1.8V, 2.0V, 2.5V, 3.3V, 5.0V 2.40 x 0.510 x 0.327 inches
61.0 x 12.95 x 8.3mm		POL Converter PCB Mount


EC7B		PDF209-18VDC, 18-36VDC, 36-72VDCSingle, Dual 1.8V, 2.5V, 3.3V, 5V, 12V, 15V, ±12V, ±15V1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm		Remote Inhibit / Trim, 2:1 Input


EC1SC		PDF209-36VDC, 18-72VDCSingle, Dual 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V2.00 x 1.60 x 0.45 inches
50.8 x 40.6 x 11.4mm		Pi Filter, Remote Inhib., UL Recognized, 4:1 Input Range


EC7BW		PDF209-36VDC, 18-75VDCSingle 3.3V, 5V, 12V, 15V1.00 x 2.00 x 0.40 inches
25.4 x 50.8 x 10.2 mm		DC-DC Converter PCB Mount


EC3SCW		PDF209-36VDC, 18-75VDCSingle 3V, 5V, 12V, 15V2.00 x 1.60 x 0.40 inches
50.8 x 40.6 x 10.2mm		DC-DC Converter PCB Mount


EC6C		PDF259-18VDC, 18-36VDC, 36-72VDCSingle, Dual, Triple 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V, 5/±12V, 5/±15V2.00 x 2.00 x 0.40 inches
50.8 x 50.8 x 10.2 mm		Industry Standard Pin out, 1-3 Outputs / Remote Inhibit, 2:1 Input / Trim


EC5E		PDF259-18VDC, 18-36VDC, 36-72VDCSingle, Dual, Triple 3.3V, 5V, 12V, 15V, ±5V, ±12V, ±15V, 5/±12V, 5/±15V, +5/+12/-5V2.56 x 3.00 x 0.83 inches
65 x 76.2 x 21.1 mm		industry Standard Pin out, 2:1 Input / Trim


EC6E		PDF259-18VDC, 18-36VDC, 36-72VDCSingle, Dual, Triple 5V, 12V, 15V, ±12V, ±15V, 5/±12V, 5/±15V, +5/+12/-5V2.56 x 3.00 x 0.83 inches
65 x 76.2 x 21.1 mm		Industry Standard Pin out, 4:1 Input / Trim


CHB50		PDF259-18VDC, 18-36VDC, 36-75VDCSingle 2.5V, 3.3V, 5V, 12V, 15V, 24V2.28 x 2.40 x 0.50 inches
57.9 x 61.0 x 12.7 mm		DC-DC Converter PCB Mount


CHB50W		PDF259-36VDC, 18-75VDCSingle 3.3V, 5V, 12V, 15V, 24V2.28 x 2.40 x 0.50 inches
57.9 x 61.0 x 12.7		DC-DC Converter PCB Mount


CEB75		PDF3036-75VDCSingle 1V,1.2V, 1.5V, 1.8V, 2.5V, 3.3V, 5V, 12V2.30 x 0.90 x 0.39 inches
58.4 x 22.9 x 10.0mm		DC-DC Converter PCB Mount


CHB75		PDF389-18VDC, 18-36VDC, 36-75VDCSingle 2.5V, 3.3V, 5V, 12V, 15V, 24V2.28 x 2.40 x 0.50 inches
57.9 x 61.0 x 12.7mm		DC-DC Converter PCB Mount


CHB75W		PDF389-36VDC, 18-75VDCSingle 3.3V, 5V, 12V, 15V, 24V2.28 x 2.40 x 0.50 inches
57.9 x 61.0 x 12.7		Half Brick, 4:1 Input, Single Output


CQB125		PDF4036-75VDCSingle 1V, 1.2V, 1.5V, 1.8V, 2.5V, 3.3V, 5V, 12V2.30 x 1.45 x 0.42 inches
58.4 x 36.8 x 10.6mm		DC-DC Converter PCB Mount


EC7C		PDF409-18VDC, 18-36VDC, 36-75VDCSingle, Dual, Triple 2.5V, 3.3V, 5V, 12V, 15V, ±12V, ±15V, 3.3V/5.0V, 3.3/±12V, 3.3/±15V, 5.0/±12V, 5.0/±15V2.00 x 2.00 x 0.40 inches
50.8 x 50.8 x 10.2 mm		DC-DC Converter PCB Mount


PKQ75		PDF5018-36VDC, 36-75VDCSingle 1.8V, 2.5V, 3.3V, 5V1.45 x 2.28 x 0.50 inches
36.8 x 57.9 x 12.7 mm		DC-DC Converter PCB Mount


CHB100		PDF5018-36VDC, 36-75VDCSingle 2.5V, 3.3V, 5V, 12V, 15V, 24V2.28 x 2.40 x 0.50 inches
57.9 x 61.0 x 12.7mm		DC-DC Converter PCB Mount


CHB100W		PDF669-36VDC, 18-75VDCSingle 3.3V, 5V, 12V, 15V, 24V2.28 x 2.40 x 0.50 inches
57.9 x 61.0 x 12.7mm		DC-DC Converter PCB Mount


CHB75-Dual		PDF7518-36VDC, 36-75VDCDual 2.5V, 3.3V, 5V2.28 x 2.40 x 0.52 inches
57.9 x 61.0 x 13.2mm		DC-DC Converter PCB Mount


CHB150		PDF7536-75VDCSingle 2.5V, 3.3V, 5V, 12V, 15V, 24V2.28 x 2.40 x 0.50 inches
57.9 x 61.0 x 12.7mm		DC-DC Converter PCB Mount


CQB75W		PDF759-36VDC, 18-75VDCSingle 3.3V, 5V, 12V, 15V, 24V1.45 x 2.28 x 0.50 inches
36.8 x 57.9 x 12.7 mm		DC-DC Converter PCB Mount


CHB150W		PDF999-36VDC, 18-75VDCSingle 3.3V, 5V, 12V, 15V, 24V2.28 x 2.40 x 0.52 inches
57.9 x 61.0 x 13.2mm		DC-DC Converter PCB Mount


CQB100W		PDF10018-75VDCSingle 3.3V, 5V, 12V, 15V, 24V1.45 x 2.26 x 0.50 inches
36.8 x 57.9 x 12.7 mm		DC-DC Converter PCB Mount


CFB200		PDF10036-75VDCSingle 2.5V, 3.3V, 5V, 12V, 15V, 24V, 28V, 48V4.60 x 2.40 x 0.52 inches
116.8 x 61.0 x 13.2mm		DC-DC Converter PCB Mount


CHB200W		PDF13218-75VDCSingle 3.3V, 5V, 12V, 15V, 24V2.28 x 2.40 x 0.52 inches
57.9 x 61.0 x 13.2mm		DC-DC Converter PCB Mount


IBQ		PDF18042-53VDC, 36-75VDCSingle 12V2.28 x 1.45 x 0.40 inches
57.9 x 36.8 x 10.2mm		DC-DC Converter PCB Mount

Elektra

Series  DataSheet    Power  Input RangeOutputsDimensionsFeatures

CK		PDF35-24VSingle: 5V, 12V, 15V Dual: ±5V, ±12V, ±15V20x 32x 10 mmSingle/Dual DC/DC PCB Mount Converter


CMR		PDF35-24VSingle: 5V, 12V, 15V Dual: ±5V, ±12V, ±15V20x 32x 10 mmSingle/Dual DC/DC PCB Mount Converter


CKW		PDF39~36VSingle: 5V, 12V, 15V Dual: ±12V, ±15V20x 32x 10 mmSingle/Dual DC/DC PCB Mount Converter


SRM		PDF69~36VSingle: 5V, 12V20x 32x 10 mmSingle DC/DC Switching Regulator


SA		PDF129~72VSingle: 5V, 12V, 15V Dual: ±12V, ±15V51x 25.4x 10 mmSingle/Dual DC/DC PCB Mount Converter


SRA		PDF159~36VSingle: 5V, 12V51x 25.4x 10 mmSingle DC/DC Switching Regulator


SB		PDF159~72VSingle: 5V, 12V, 15V Dual: ±12V, ±15V51x 51x 10 mmSingle/Dual DC/DC PCB Mount Converter


EA		PDF509~36VSingle: 5V, 12V, 24V58x 61x 13 mmSingle DC/DC PCB Mount Converter


SRB		PDF509~36VSingle: 5V, 12V86x 41x 12 mmSingle DC/DC Switching Regulator


SC		PDF759~72VSingle: 5V, 12V, 24V Dual: ±12V, ±15V Triple: 5/±12V, 5/±15V89x 64x 15 mmSingle/Dual/Triple DC/DC PCB Mount Converter


EB		PDF759~72VSingle: 5V, 12V, 24V117x 61x 13 mmSingle DC/DC PCB Mount Converter



| Adapter Tech | AJ Power | APTronic | Arch Electronics | Bestec | Cincon | Elektra | Exeltech | Integrated Power Designs | Lustrous |
© 2009 Current Solutions, Inc. | Contact Us | User Agreement | |
mean well power supply supplies power supply information oem led components power supply, power supplies, converter, inverter, AC/DC, DC/DC, AC/AC, DC/AC, switching, Mean Well, arch, pduke, interpower, aims power, adaptertech, arch electronics, ipd, integrated power designs, powermate technology, powerstax, led, led drivers, switcher, switch mode, oem
